Installing a Kitchen Extractor Fan: A Step-by-Step Guide
For homeowners looking to improve their kitchen's ventilation, installing a kitchen extractor fan can be a rewarding DIY project. Here's a comprehensive guide on how to install a ducted kitchen extractor fan.
Preparation
Before you begin, it's essential to prepare for the installation process. Turn off the electricity supply to any applicable power outlets at the consumer unit. Gather the necessary tools and materials, which include an SDS drill, diamond core drill bit, combi drill, masonry drill bits, laser level, tape measure, pencil, hammer, extractor unit, ducting kit or cooker hood termination kit (if ducted), sealant (if ducted), screws, wall plugs, duct tape, gloves, goggles, ear protection, and a step ladder.
Step 1: Plan the Duct Location
Choose the shortest, straightest route for the duct from the fan to an exterior vent (wall or roof), avoiding obstructions like studs, plumbing, or electrical wiring for better airflow.
Step 2: Measure and Mark
Measure the duct opening on the extractor fan and where the duct passes through the wall/ceiling accurately. Mark the cut lines carefully to avoid mistakes.
Step 3: Cut the Opening
Use a drywall saw to cut the marked opening for the duct and fan installation.
Step 4: Attach the Duct Adapter
If your extractor doesn’t have a built-in adapter, fix the duct adapter/collar to the fan outlet using sheet metal screws for a secure fit.
Step 5: Install the Fan Bracket
Mount the fan bracket or housing inside the ceiling or wall opening using self-tapping screws, ensuring it fits securely in place.
Step 6: Connect Electrical Wiring
Connect the fan wiring to your home’s electrical box, including grounding properly. Plug in the fan power connector as per the manufacturer instructions.
Step 7: Attach the Duct to Fan Outlet
Slide the duct over the adapter and seal with duct tape or clamps to prevent leaks.
Step 8: Run the Duct to Exterior Vent
Extend the duct through the wall or roof vent ensuring minimal bends and secure it firmly along the way.
Step 9: Install the Exterior Vent Cap
Fit the vent cap on the outside of your home to keep out pests and weather.
Step 10: Fit the Fan Cover
Attach the fan’s grille or cover using mounting springs or screws to finish the installation.
Safety Considerations
Always ensure the power is off before wiring and use appropriate safety equipment. If unsure, consult a professional electrician, especially when dealing with electrical connections. Drilling the vent hole can be dangerous and may be unsuitable for most DIYers; consider hiring an experienced person if unsure.
Additional Tips
Wearing PPE, including a dust mask, goggles, work gloves, and hearing protection, is recommended during the installation process. The hole should be fractionally wider than the ducting; for example, a 150mm ducting would require a 152mm bit. When drilling, remove loosened material as you go to prevent the diamond core drill bit from overheating and deforming.
If the extractor is a recirculating model, you'll also need to install the charcoal and grease filters before use. When installing a ducted extractor, mark the circle on the external wall or ceiling through which the ducting will channel cooking fumes out of the room using a laser level to ensure alignment.
Conclusion
Installing a kitchen extractor fan can be a satisfying and money-saving measure for some DIYers. For those who prefer a professional touch or face challenges with electrical work, hiring a qualified electrician is always an option. If your kitchen requires even more ventilation, consider installing an additional standalone electric extractor fan.
